Giant Propel ADV 1 Carbon Smoke '27
Pickup currently unavailable
GIANT PROPEL ADV 1
Get the most from your hard-earned pedalling power. Whether it's squeezing our more speed on solo rides or taking bragging rights in the group, the new lighter, smoother Propel Advanced makes the thrill of the road accessible to all. A lightweight composite frameset with AeroSystem Shaping technology forms the heart of this reengineered road machine. It's designed as a full-bike solution to minimizing resistance, integrating the frame and components more seamlessly to help unlock higher speeds. The cockpit gives it a sleek aero profile with internal cable routing, while the Vector seatpost combines aero shaping with added compliance to help smooth out bumps and road vibrations. An integrated WheelSystem with 50mm deep rims and tubeless aero tires reduce rolling resistance, while added frame and fork clearance let you run high-volume tires (up to 32mm) for smooth, efficient control.
ADVANCED COMPOSITE TECHNOLOGY
Giant’s High Performance Grade raw carbon material is used to produce this custom frame material in our own composite factory with a high stiffness-to-weight ratio. The front triangle of these framesets is assembled and molded as one continuous piece in a proprietary manufacturing process called Modified Monocoque Construction.
PRODUCT HIGHLIGHTS
- Integrated aerodynamics: AeroSystem Shaping, a result of CFD analysis and dynamic wind-tunnel testing, optimizes aerodynamic performance at every yaw angle. The truncated ellipse airfoil tube shapes and all-new Contact SL Aero cockpit produce superior aero performance.
- Race-winning efficiency: Advanced-grade composite frame and hybrid alloy/composite fork deliver optimal stiffness and weight savings. The result is an even greater stiffness-to-weight advantage.
- Easier adjustability: All-new cable routing through the stem and head tube makes it quicker and easier to adjust or change cockpit components and fine-tune performance and riding position.
SPECIFICATIONS:
FRAME: ADVANCED-GRADE COMPOSITE, 12X142MM THRU-AXLE, DISC
FORK: ADVANCED-GRADE COMPOSITE, FULL-COMPOSITE OVERDRIVE AERO STEERER, 12X100MM THRU-AXLE, DISC
SHOCK: N/A
HANDLEBAR: GIANT CONTACT SL AERO, XS:380/360MM, S:380/360MM, M:400/370MM, M/L:400/370MM, L:420/390MM, XL:420/390MM
GRIPS: STRATUS LITE 2.0
STEM: GIANT CONTACT SL AERO, XS:80MM, S:90MM, M:100MM, M/L:110MM, L:110MM, XL:120MM
SEATPOST: GIANT VECTOR, COMPOSITE, -5/+15MM OFFSET
SADDLE: GIANT FLEET SL
PEDALS: PLATFORM PEDAL [GCS,GTS], N/A [ALL OTHER GSC]
SHIFTERS: SHIMANO 105 DI2
FRONT DERAILLEUR: SHIMANO 105 DI2
REAR DERAILLEUR: SHIMANO 105 DI2
BRAKES: SHIMANO 105 DI2 HYDRAULIC, SHIMANO RT-CL700 ROTORS, [F]160MM, [R]140MM
BRAKE LEVERS: SHIMANO 105 DI2 HYDRAULIC
CASSETTE: SHIMANO 105, 12-SPEED, 11X36
CHAIN: KMC X12L-1
CRANKSET: SHIMANO 105 DI2, 36/52, XS:165MM, S:165MM, M:170MM, M/L:170MM, L:172.5MM, XL:172.5MM
BOTTOM BRACKET: SHIMANO, PRESS FIT
RIMS: GIANT SLR 2 50 CARBON DISC WHEELSYSTEM, [F]50MM, [R]50MM
HUBS: [F] GIANT AERO HUB, CENTERLOCK, [R] GIANT AERO HUB, 3-PAWL DRIVER, CENTERLOCK, 12MM THRU-AXLE
SPOKES: SAPIM
TYRES: GIANT GAVIA COURSE 0, TUBELESS,700X28C, FOLDING
EXTRAS: COMPUTER MOUNT, WATER BOTTLE CAGES, TUBELESS PREPARED, 32MM MAX TIRE SIZE
WEIGHT: HOW MUCH DOES THIS BIKE WEIGH? THIS IS A COMMON QUESTION, BUT THE TRUTH IS THAT THERE IS NO INDUSTRY STANDARD FOR SETTING A WEIGHT. WE AT GIANT BELIEVE THE ONLY WAY TO TRULY FIND THE WEIGHT OF A PARTICULAR BIKE IS TO GO TO YOUR LOCAL DEALER.
