ZIPP 454 NSW WHEELSET
Zipp’s 454 NSW Tubeless Disc-brake is the ultimate road racing wheelset. This wheel delivers everything the performance cyclist demands. It’s aerodynamically efficient and stable in all wind conditions. What’s more, a wider rim is designed for tubeless tires at lower pressure for reduced rolling resistance and vibration damping, so you’ll lose as little energy as possible out on the road. For the best combination of aerodynamics and rolling resistance gains a 28mm tire is recommended on this wheel. Its undulating 58mm Sawtooth rim shape with Hyperfoils is our most aerodynamic and stable wheel.
The 454 NSW features Zipp’s Total System Efficiency (TSE), our approach at combatting the biggest enemies of speed: wind resistance, gravity, rolling resistance, and vibration losses. And gravity? Zipp’s use of hookless (straight side) rims in the 454 NSW is integral to Making You Faster. With hookless, the transition between the tire and the rim is more seamless and aero.
Zipp’s hookless rims have more efficient resin distribution, which means lighter, stronger wheels. The 454 NSW features the premium ZR1 SL hubset with ceramic bearings and 66 points of engagement. The hubset also is 30 g lighter than the predecessor hub in NSW wheels.
PRODUCT HIGHLIGHTS
- The 454 NSW Tubeless Disc brake is roughly a pound (more than 400 grams) lighter than its predecessor!
- ZR1 SL hubset with ceramic bearings
- TSE™ for greater efficiency and reduced rolling resistance
- Sawtooth™ rim with Hyperfoil™ nodes and HexFin™ ABLC dimple pattern for top aero and crosswind-stability performance with an undulating 53/58mm rim depth
- Zipp graphics applied using Zipp’s ImPress™ direct-print technology
- XDR™ or SRAM/Shimano driver bodies
- Ships with 12mm front and rear end caps
- Center locking rotor interface. Lockring is included with the wheels
- Campagnolo driver body sold separately
- 1400 g
- Lifetime warranty
- Model ID: WH-454-NTLD-C1
SPECIFICATIONS:
SIZE (WHEELS): 700C
RIM CONSTRUCTION: CARBON – HOOKLESS
TIRE COMPATIBILITY: TUBELESS TIRES ONLY
RIM DEPTH: 58MM
BRAKE COMPATIBILITY: DISC (CENTER LOCK)
RIM - INSIDE WIDTH: 23MM
RIM PROFILE: SYMMETRICAL
RIM FINISH: UD FIBER, IMPRESS TECHNOLOGY
NIPPLE MATERIAL: ALUMINUM
SPOKE TYPE: CX-RAY - BLACK
SPOKE COUNT: 24
SPOKE PATTERN: 2 CROSS
HUB: COGNITION V2
DRIVER BODY TYPE: N/A, SRAM XDR, SRAM/SHIMANO ROAD
AXLE TYPE (WHEELS): TA 12X100, TA 12X142
BEARINGS: CARTRIDGE - CERAMIC
MAX TIRE PRESSURE: 73PSI/5.0BAR
MAX RECOMMENDED SYSTEM WEIGHT: 250LBS/114KG
SPOKE LENGTH DS: 248MM, 254MM
SPOKE LENGTH NDS: 252MM, 254MM
MAX OUTSIDE WIDTH: 28MM
WEIGHT (G): 1428
WEIGHT BASED ON: ESTIMATED LIGHTEST WEIGHT FOR WHEELSET CONFIGURATION: 12MM THROUGH AXLES AND XDR BODY. NO TAPE OR VALVE INCLUDED IN WEIGHT.
