Cannondale Moterra Neo SL LAB71 Pewter '24

CANNONDALE MOTERRA SL LAB71

An eMTB to rule them all. Built for ultimate command of any trail, with top-of-the-line Fox Factory 36 fork and shock, the remarkable DT Swiss XMC 1501 carbon wheels, a Reverb AXS wireless dropper, the slick shifting of SRAM’s XX wireless electronic group, and the lightweight OneUp handlebar and stem. The LAB71 Moterra SL is simply the ultimate electric trail bike.

PRODUCT HIGHLIGHTS

• LAB71, full carbon, 150mm travel FlexPivot frame with Proportional Response suspension kinematics and geometry
• Top-of-the-line Fox Factory suspension – 160mm Factory Float 36 fork & Factory Float X rear shock
• Ultralight and tough DT Swiss XMC 1501 carbon, tubeless-ready, all-mountain wheelset
• SRAM’s top e-MTB group - XX AXS wireless 12-speed shifting & Code Ultimate Stealth 4-piston hydraulic disc brakes, plus e*thirteen Race Carbon cranks
• RockShox’s wireless remote Reverb AXS dropper post, and a OneUp stem and Carbon Ebar
• Cannondale-tuned Shimano EP801 motor & custom, high-energy-density 601Wh internal battery

SPECIFICATIONS:

FRAME: LAB71 MOTERRA SL CARBON, 150MM TRAVEL, PROPORTIONAL RESPONSE TUNED SUSPENSION, FLEXPIVOT CHAINSTAY, DIRECT MOUNT INTERNAL BATTERY, ENGINEERED PLASTIC SKID PLATE, 55MM CHAINLINE, INTERNAL CABLE ROUTING, 29” FLIPCHIP, 148X12MM MAXLE THRU-AXLE, UDH HANGER, 200MM NATIVE POST MOUNT BRAKE, ANGLE ADJUST HEADSET
FORK: FOX FLOAT FACTORY 36, 160MM TRAVEL, GRIP2 DAMPER, KASHIMA COATING, 15X110MM KABOLT THRU-AXLE, TAPERED STEERER, 44MM OFFSET
HEADSET: ACROS ADJUSTABLE ANGLE (1.2°)
REAR SHOCK: FOX FLOAT X FACTORY, 2 POS ADJ, EVOL LV, 210X55MM
DRIVE UNIT: SHIMANO EP801, 85NM, CUSTOM TUNED, WALK, ECO, TRAIL 1, TRAIL 2, BOOST MODES
BATTERY: CUSTOM 601WH BATTERY
CHARGER: CUSTOM 4A
DISPLAY: SHIMANO SC-EM800 CYCLE COMPUTER, BLUETOOTH LE COMPATIBLE
CERTIFICATIONS: UL 2849
REAR DERAILLEUR: SRAM XX EAGLE AXS, T-TYPE
SHIFTERS: SRAM EAGLE AXS T-TYPE ULTIMATE POD CONTROLLER
CHAIN: SRAM XX EAGLE, T-TYPE, FLATTOP
CRANK: E*THIRTEEN E*SPEC RACE CARBON - GEN 4, 165MM, 34T
REAR COGS: SRAM XX EAGLE, T-TYPE, 10-52, 12-SPEED
BRAKES: SRAM CODE ULTIMATE STEALTH, 4-PISTON HYDRAULIC DISC, 200MM HS2 ROTORS
BRAKE LEVERS: SRAM CODE ULTIMATE STEALTH
RIMS: DT SWISS XMC 1501, CARBON, 30MM INNER WIDTH, HOOKLESS, TSS TUBELESS READY
SPOKES: DT SWISS COMPETITION RACE
TIRE SIZE: 2.5
WHEEL SIZE: 29
HUBS: (F) DT SWISS 240, 15X110MM / (R) DT SWISS 240 RATCHET EXP 36, 12X148MM
TIRES: (F) MAXXIS DHF, 29X2.5 ", 3C, EXO+, TUBELESS READY / (R) MAXXIS DISSECTOR , 27.5X2.4", 3C, EXO+, TUBELESS READY
HANDLEBAR: ONEUP CARBON EBAR, 35MM CLAMP, 35MM RISE, 8° SWEEP, 5° RISE, 780MM
STEM: ONEUP STEM, 6061 ALLOY, 1-1/8", 35MM, 0°
GRIPS: CANNONDALE TAPERRIDGE
SADDLE: FIZIK TERRA RIDON X1, 145MM, WINGFLEX, CARBON MOBIUS RAIL 7X10MM
SEATPOST: ROCKSHOX REVERB AXS, 31.6, 150MM (S), 170MM (M-XL)
EXTRA: TUBELESS VALVES, SRAM AXS CHARGER

VIEW MORE DETAILS ON WWW.CANNONDALE.COM

*Please note that bike specifications are subject to change without prior notice.
