Zipp 303 XPLR S Wheelset
ZIPP 303 XPLR S WHEELSET
The Zipp 303 XPLR S is big upgrade for gravel riders without a big price tag. This wheelset borrows key innovations from our premium wide gravel wheelset, it is affordable and robust for discerning gravel riders. This wheelset is the fastest on gravel, thanks to its mega-wide rim that integrates seamlessly with approved gravel racing tires.*
In gravel, resistance and vibrations from bumpy surfaces create a barrier that slows riders down. To combat this, Zipp applied Total System Efficiency specifically to the challenges of gravel. The wide profile increases air volume, allowing for lower tire pressures without squirm. That means you mitigate surface vibrations while maintaining grip when cornering or traction while climbing.
The rim profile also creates a seamless transition with gravel tires for unsurpassed aero efficiency on gravel. And while the 303 XPLR S is built big, it’s light to keep you fast and fresh for those long, fulfilling days in the saddle. The Zipp 303 XPLR S is compatible only with approved tires, click here for the ZIPP tire compatibility chart.
Note for MicroDrive users: XPLR S is only available with Rear Hub Bodies in SRAM XDR or Shimano HG only. XPLR S wheels can not be upgraded to Shimano MicroDrive. You can only do that with 303 XPLR SW
PRODUCT HIGHLIGHTS
- Fast and robust gravel wheel, features tubeless and hookless rim profile
- Ultra-wide internal profile for decreased rolling resistance, ability to run pressures under 30psi (2.1 bars)
- Wide and deep profile integrates seamlessly with gravel tires to increase aerodynamic efficiency
- Applies Zipp’s Total System Efficiency to high-performance gravel
- 76 / 176 DB hubs with Center locking interface XDR or SRAM/Shimano driver bodies
- Ships with 12mm front and rear end caps
- Max tire pressure 50 psi/3.45 bar
- Lifetime Warranty
- *303 XPLR S IS ONLY COMPATIBLE WITH APPROVED TIRES. The Goodyear XPLR Slick and Goodyear XPLR Inter are specifically designed and optimized for the 303 XPLR S.
- Model ID: WH-303-XPS-A1
SPECIFICATIONS:
SIZE (WHEELS): 700C
RIM CONSTRUCTION: CARBON – HOOKLESS
TIRE COMPATIBILITY: TUBELESS TIRES ONLY
RIM DEPTH: 54MM
BRAKE COMPATIBILITY: DISC (CENTER LOCK)
RIM - INSIDE WIDTH: 32MM
RIM PROFILE: SYMMETRICAL
RIM FINISH: UD FIBER, ADHESIVE DECALS
NIPPLE MATERIAL: BRASS
SPOKE TYPE: CX-SPRINT
SPOKE COUNT: 24
SPOKE PATTERN: 2 CROSS
HUB: 176D, 76D
DRIVER BODY TYPE: SRAM XDR OR SHIMANO HG ONLY. XPLR S WHEELS CAN NOT BE UPGRADED TO SHIMANO MICRODRIVE. YOU CAN ONLY DO THAT WITH 303 XPLR SW
AXLE TYPE (WHEELS): TA 12X100, TA 12X142
BEARINGS: CARTRIDGE - STAINLESS STEEL
MAX TIRE PRESSURE: 50PSI/3.45BAR
MAX RECOMMENDED SYSTEM WEIGHT: 298LBS/135KG
SPOKE LENGTH DS: N/A
SPOKE LENGTH NDS: N/A
MAX OUTSIDE WIDTH: 40MM
WEIGHT (G): 1610
WEIGHT BASED ON: SRAM XDR OR SHIMANO HG ONLY. XPLR S WHEELS CAN NOT BE UPGRADED TO SHIMANO MICRODRIVE. YOU CAN ONLY DO THAT WITH 303 XPLR SW: <A HREF="HTTPS://SHOP.SRAM.COM/COLLECTIONS/WHEELS-GRAVEL/PRODUCTS/303-XPLR-SW" TARGET="_BLANK" REL="NOOPENER">303 XPLR SW</A>
