Outer The Link NX

OUTER THE LINK-NX

The Link is our no nonsense, go anywhere E-bike. Featuring 160mm front and rear suspension travel and a progressively tuned four bar suspension layout, this bike is ready for to take on anything you can throw at it. The 85nm motor and 630Wh battery mean there is plenty of power and range to get you to the highest peaks or for cramming in as many party laps as possible with the squad.

PRODUCT HIGHLIGHTS

• There are lots of things we like about this bike, but here are the main things:

• 85N.m Shimano EP8 Motor (32Kph)

• 630Wh Shimano Battery

• 160mm front and rear suspension travel

• Large standard size sealed bearings

• Lyne Components dropper post, cockpit and rims

SPECIFICATIONS

FRAME: ALLOY 29” BOOST, 160MM TRAVEL, UDH HANGER, INTEGRATED BATTERY
WHEEL SIZE: 29” FRONT AND REAR
FORK: ROCKSHOX 35 GOLD RL 160MM 44MM OFFSET
REAR SHOCK: ROCKSHOX DELUXE SELECT R 205 X 62.5MM
REAR DERAILLEUR: SRAM GX EAGLE 12 SPEED
SHIFTER: SRAM NX EAGLE 12 SPEED
CASSETTE: SRAM CS PG1230 EAGLE 11-50T
CHAIN: SRAM NX EAGLE
HEADSET: FSA NO.57
REAR TYRE: MAXXIS AGGRESSOR, 29X2.5WT, 120TPI X2, FOLDABLE, DD/TR
FRONT TYRE: MAXXIS ASSEGAI, 29X2.5WT, 120TPI, FOLDABLE, 3CT MAXXTERRA/EXO+/TR
WHEELSET: LYNE AMP HD RIMS, NOVATEC HUBS
BRAKES: SRAM DB8
ROTORS: SRAM CENTERLINE 200MM FRONT, 180MM REAR
CRANKSET: SHIMANO M600 170MM, 34T CHAINRING
HANDLEBARS: LYNE AMP 20MM RISE, 800MM WIDTH, INTEGRATED CABLE ROUTING
STEM: LYNE AMP 35 BAR CLAMP, 35MM S & M, 50MM L & XL
SEATPOST: LYNE CONTOUR V2.0 INTERNAL DROPPER POST - 150MM TRAVEL
SADDLE: OUTER 140MM
GRIPS: LYNE COSMIC CACTUS LOCK-ON BLACK
BATTERY: SHIMANO 630WH INTEGRATED
DRIVE UNIT: SHIMANO EP8 (32 KM/H)
BATTERY CHARGER: SHIMANO EC-E8004
FRAME WARRANTY: 5 YEARS
WEIGHT: +/-25.2 KG (SIZE SMALL, PLEASE ALLOW FOR SOME DEVIATION)

VIEW MORE DETAILS ON WWW.OUTERCYCLES.COM

*Please note that bike specifications are subject to change without prior notice.
